    Corrosion Resistance Tungsten Carbide Valve Seat Ball For Oil Gas Fields​

    Carbide Corrosion Resistance Valve Seat And Ball For Oil Gas Fields​


    Hard metal ball valve or hard metal ball valve is a further development of traditional plug valve.

    The opening and closing part is a sphere, and the purpose of opening and closing is realized by the sphere around the axis of the valve stem. Widely used in oil wells and deep-sea drilling, the pump valve ball and ball seat are also one of the key components of the pump.


    Due to the extremely working environment and conditions of the petroleum drilling industry, sand wells, heavy oil wells, and high-pressure oil repellent wells usually contain water, various gases, wax, sand and other highly corrosive substances required by oil wells.



    Corrosion Resistance Tungsten Carbide Valve Seat Ball For Oil Gas Fields​

    • Recommened carbide grades for Oil/Gas wear parts:

    Cobalt Binder Grades

    GradeBinder
    (Wt %)
    Density
    (g/cm3)
    Hardness
    (HRA)
    TRS
    (≥N/mm²)
    YG6614.8901520
    YG6X614.9911450
    YG6A614.9921540
    YG8814.789.51750
    YG121214.2881810
    YG151514872050
    YG202013.585.52450
    YG252512.1842550

    Nickel Binder Grades

    GradeBinder
    (Wt %)
    Density
    (g/cm3)
    Hardness
    (HRA)
    TRS
    (≥N/mm²)
    YN6614.789.51460
    YN6X614.890.51400
    YN6A614.8911480
    YN8814.688.51710
